The BC-20 OS is a permanently-installed online corona monitoring system for 24/7 surveillance of substations and switchgear. Network connectivity enables remote real-time detection without manual inspection visits.
UV Optical
Spectral Range
240 ~ 280nm (solar-blind)
Min. Discharge Sensitivity
1 Pc/10m
Visible
Channel
Colour camera, co-axial with UV
System
Operation Mode
24/7 continuous monitoring
Alarm
Configurable photon threshold
Data Recording
Continuous log with timestamp
Power
Physical
Mounting
Fixed (pole / wall / ceiling)
Protection
Weatherproof outdoor housing
Operating Temperature
-20°C ~ +60°C
Certifications
