Name: BT-63 Infrared Thermometer — BT-63 IR thermometer, -60~+800°C, D:S 20:1, colour bar graph display, adjustable
Brand: Mellon
Availability: InStock

Overview

KEY HIGHLIGHTS

The BT-63 extends the BT-62's range to +800°C and adds a 20:1 D:S ratio for more distant targets. The colour bar graph display provides instant visual temperature indication, ideal for industrial process monitoring and metal fabrication.

Range extended to +800°C for industrial use
High D:S ratio 20:1 for distant targets
Colour bar graph temperature display
Adjustable emissivity 0.1–1.0
Low Voltage Technology — AAA batteries

Technical Data

SPECIFICATIONS

Measurement

Type

IR Thermometer + Laser + Colour Bar

Range

-60 ~ +800°C (-76 ~ +1472°F)

Operating Range

0 ~ 50°C

Accuracy

±1.5°C (2.7°F)

Emissivity

0.95 default, adjustable 0.1-1.0

Resolution

0.1°C / 0.1°F

Response Time

1 sec

D:S Ratio

20:1

Power

Supply

AAA x 2 alkaline

Battery Life

~8 hours

Physical

Dimensions

38 x 108 x 162 mm

Weight

~150 g (with batteries)

Certifications

Documentation

DOWNLOADS

Product Datasheet

BT-62 / 63 / 64 / 65 / 66 Specification

PDF · English

Download

Operation Manual

BT-62 ~ BT-66 Series Manual

PDF · English

Download
